Build an *Advanced* AI-Powered Technical Analysis Stock Dashboard with Google Gemini 2.0 Flash

Gemini 2.0 Flash + Streamlit = Technical Analysis Intelligence

A few months ago, I shared a video exploring the use of LLM vision models to interpret stock market technical indicator charts. The case study featured Meta’s Llama 3.2 Vision model running locally via an Ollama server. I aimed to make this accessible to those with older hardware—like my five-year-old MacBook—without relying on paid services from OpenAI or Google.

But it turns out the Llama 3.2 Vision model kinda sucks for this task.

So, I decided to revisit the idea with the latest multimodal Google Gemini 2.0 models, with a focus on automation and scale. In this tutorial, we’ll prioritize performance over cost and build an updated AI-powered technical analysis dashboard that delivers buy/hold/sell decisions for your entire portfolio within seconds.

Full Code Below the Video

Important Note: This video is not financial or investing advice. It is an educational tutorial on how to use AI/LLM vision models in Python. Also, don't blindly trust the results of LLM model results without critical thinking or subject matter expertise 🧠. LLM's are still experimental technology that have high error rates.

Premium Code (NEW)

• Includes additional technical indicators, ability to quickly customize parameters of technical indicators, and advanced charting

• Purchase Here: https://deep-charts-shop.fourthwall.com/products/premium-ai-powered-technical-analysis-dashboard-python-starter-template

Full Code (As Seen In Tutorial)

## AI-Powered Technical Analysis Dashboard (Gemini 2.0)
## Source: https://www.youtube.com/@DeepCharts

# Libraries
import streamlit as st
import yfinance as yf
import pandas as pd
import plotly.graph_objects as go
import google.generativeai as genai
import tempfile
import os
import json
from datetime import datetime, timedelta

# Configure the API key - IMPORTANT: Use Streamlit secrets or environment variables for security
# For now, using hardcoded API key - REPLACE WITH YOUR ACTUAL API KEY SECURELY
GOOGLE_API_KEY = "your api key goes here"
genai.configure(api_key=GOOGLE_API_KEY)

# Select the Gemini model - using 'gemini-2.0-flash' as a general-purpose model
MODEL_NAME = 'gemini-2.0-flash' # or other model
gen_model = genai.GenerativeModel(MODEL_NAME)

# Set up Streamlit app
st.set_page_config(layout="wide")
st.title("AI-Powered Technical Stock Analysis Dashboard")
st.sidebar.header("Configuration")

# Input for multiple stock tickers (comma-separated)
tickers_input = st.sidebar.text_input("Enter Stock Tickers (comma-separated):", "AAPL,MSFT,GOOG")
# Parse tickers by stripping extra whitespace and splitting on commas
tickers = [ticker.strip().upper() for ticker in tickers_input.split(",") if ticker.strip()]

# Set the date range: start date = one year before today, end date = today
end_date_default = datetime.today()
start_date_default = end_date_default - timedelta(days=365)
start_date = st.sidebar.date_input("Start Date", value=start_date_default)
end_date = st.sidebar.date_input("End Date", value=end_date_default)

# Technical indicators selection (applied to every ticker)
st.sidebar.subheader("Technical Indicators")
indicators = st.sidebar.multiselect(
    "Select Indicators:",
    ["20-Day SMA", "20-Day EMA", "20-Day Bollinger Bands", "VWAP"],
    default=["20-Day SMA"]
)

# Button to fetch data for all tickers
if st.sidebar.button("Fetch Data"):
    stock_data = {}
    for ticker in tickers:
        # Download data for each ticker using yfinance
        data = yf.download(ticker, start=start_date, end=end_date)
        if not data.empty:
            stock_data[ticker] = data
        else:
            st.warning(f"No data found for {ticker}.")
    st.session_state["stock_data"] = stock_data
    st.success("Stock data loaded successfully for: " + ", ".join(stock_data.keys()))

# Ensure we have data to analyze
if "stock_data" in st.session_state and st.session_state["stock_data"]:

    # Define a function to build chart, call the Gemini API and return structured result
    def analyze_ticker(ticker, data):
        # Build candlestick chart for the given ticker's data
        fig = go.Figure(data=[
            go.Candlestick(
                x=data.index,
                open=data['Open'],
                high=data['High'],
                low=data['Low'],
                close=data['Close'],
                name="Candlestick"
            )
        ])

        # Add selected technical indicators
        def add_indicator(indicator):
            if indicator == "20-Day SMA":
                sma = data['Close'].rolling(window=20).mean()
                fig.add_trace(go.Scatter(x=data.index, y=sma, mode='lines', name='SMA (20)'))
            elif indicator == "20-Day EMA":
                ema = data['Close'].ewm(span=20).mean()
                fig.add_trace(go.Scatter(x=data.index, y=ema, mode='lines', name='EMA (20)'))
            elif indicator == "20-Day Bollinger Bands":
                sma = data['Close'].rolling(window=20).mean()
                std = data['Close'].rolling(window=20).std()
                bb_upper = sma + 2 * std
                bb_lower = sma - 2 * std
                fig.add_trace(go.Scatter(x=data.index, y=bb_upper, mode='lines', name='BB Upper'))
                fig.add_trace(go.Scatter(x=data.index, y=bb_lower, mode='lines', name='BB Lower'))
            elif indicator == "VWAP":
                data['VWAP'] = (data['Close'] * data['Volume']).cumsum() / data['Volume'].cumsum()
                fig.add_trace(go.Scatter(x=data.index, y=data['VWAP'], mode='lines', name='VWAP'))
        for ind in indicators:
            add_indicator(ind)
        fig.update_layout(xaxis_rangeslider_visible=False)

        # Save chart as temporary PNG file and read image bytes
        with tempfile.NamedTemporaryFile(suffix=".png", delete=False) as tmpfile:
            fig.write_image(tmpfile.name)
            tmpfile_path = tmpfile.name
        with open(tmpfile_path, "rb") as f:
            image_bytes = f.read()
        os.remove(tmpfile_path)

        # Create an image Part
        image_part = {
            "data": image_bytes,
            "mime_type": "image/png"
        }

        # Updated prompt asking for a detailed justification of technical analysis and a recommendation.
        analysis_prompt = (
            f"You are a Stock Trader specializing in Technical Analysis at a top financial institution. "
            f"Analyze the stock chart for {ticker} based on its candlestick chart and the displayed technical indicators. "
            f"Provide a detailed justification of your analysis, explaining what patterns, signals, and trends you observe. "
            f"Then, based solely on the chart, provide a recommendation from the following options: "
            f"'Strong Buy', 'Buy', 'Weak Buy', 'Hold', 'Weak Sell', 'Sell', or 'Strong Sell'. "
            f"Return your output as a JSON object with two keys: 'action' and 'justification'."
        )

        # Call the Gemini API with text and image input - Roles added: "user" for both text and image
        contents = [
            {"role": "user", "parts": [analysis_prompt]},  # Text prompt with role "user"
            {"role": "user", "parts": [image_part]}       # Image part with role "user"
        ]

        response = gen_model.generate_content(
            contents=contents  # Pass the restructured 'contents' with roles
        )

        try:
            # Attempt to parse JSON from the response text
            result_text = response.text
            # Find the start and end of the JSON object within the text (if Gemini includes extra text)
            json_start_index = result_text.find('{')
            json_end_index = result_text.rfind('}') + 1  # +1 to include the closing brace
            if json_start_index != -1 and json_end_index > json_start_index:
                json_string = result_text[json_start_index:json_end_index]
                result = json.loads(json_string)
            else:
                raise ValueError("No valid JSON object found in the response")

        except json.JSONDecodeError as e:
            result = {"action": "Error", "justification": f"JSON Parsing error: {e}. Raw response text: {response.text}"}
        except ValueError as ve:
            result = {"action": "Error", "justification": f"Value Error: {ve}. Raw response text: {response.text}"}
        except Exception as e:
            result = {"action": "Error", "justification": f"General Error: {e}. Raw response text: {response.text}"}

        return fig, result

    # Create tabs: first tab for overall summary, subsequent tabs per ticker
    tab_names = ["Overall Summary"] + list(st.session_state["stock_data"].keys())
    tabs = st.tabs(tab_names)

    # List to store overall results
    overall_results = []

    # Process each ticker and populate results
    for i, ticker in enumerate(st.session_state["stock_data"]):
        data = st.session_state["stock_data"][ticker]
        # Analyze ticker: get chart figure and structured output result
        fig, result = analyze_ticker(ticker, data)
        overall_results.append({"Stock": ticker, "Recommendation": result.get("action", "N/A")})
        # In each ticker-specific tab, display the chart and detailed justification
        with tabs[i + 1]:
            st.subheader(f"Analysis for {ticker}")
            st.plotly_chart(fig)
            st.write("**Detailed Justification:**")
            st.write(result.get("justification", "No justification provided."))

    # In the Overall Summary tab, display a table of all results
    with tabs[0]:
        st.subheader("Overall Structured Recommendations")
        df_summary = pd.DataFrame(overall_results)
        st.table(df_summary)
else:
    st.info("Please fetch stock data using the sidebar.")

Subscribe to the Deep Charts YouTube Channel for more informative AI and Machine Learning Tutorials.
